LINCOLN ELECTRIC INVERTEC® CC 400-TP - EDU MODEL

BRAND: LINCOLN ELECTRIC

MODEL: INVERTEC® CC 400-TP

TECHNICAL SPECIFICATION:

  • Primary Voltage: 415V 3Ph

  • Mode:

    • MMA

    • TIG

  • Output Range:

    • MMA: 10-400A 20.4-36V

    • TIG:5-400A 10.2-26V

  • Rated Output:

    • MMA: 400A/36V/60% 310/32.4V/100%

    • TIG: 400A/26V/60% 310/22.4V/100%

  • Power Input at Rated Output: 17 KW

  • Height x Width x Depth: 480x350x730 mm

  • Weight: 34 KG

  • Processes: TIG, STICK

MACHINE C/W:

  • TIG TORCH ( HEAVY DUTY ) X 25FT

  • EARTH LEAD X 4MTR

  • ARGON REGULATOR

Advantage Lincoln

★ Advanced inverter technology for superior TIG arc performance

★ Numeric display for easy setup of all welding parameters

★ Parameter memory with 10 settable locations

★ HF, Lift ignition and HF spot welding modes for dierent welding needs

★ Complete TIG parameter presets

★ High speed pulse arc adjustment to decrease deformation and increase welding speed

★ Superior stick welding performance with arc force and hot start settings

★ Completely portable welding performance

★ Rugged and durable case design

★ IP23 rating for use in harsh environments

CATALOG DOWNLOAD HERE
