Feat Craft Pro-Stick 400 Welding Machine

BRAND: FEAT CRAFT

MODEL: Feat Craft Pro-Stick 400

SPECIFICATION:

  • Power Supply Voltage: 3-415V

  • Grid Frequency: 50/60Hz

  • Effective Current

    • MMA: 27 A

    • LIFT: 21 A

  • Rated input power

    • MMA: 17kVa

    • LIFT: 12.5kVa

  • Rated input Current

    • MMA: 35 A

    • LIFT: 27 A

  • Duty Cycle(40°C 10min):

    • 60% 400 A

    • 100% 325A

  • No Load Voltage:

    • MMA: 80

    • LIFT: 22.5

  • Welding  Current Range: 20-400A

  • Efficiency: 80%

  • Power Factor: 0.70

  • Insulation class: H

  • Protection class: IP 23

  • Cooling: AF

  • Dimensions L x W x H:485x240x445MM

  • Weight: 19 KG

  • Electrode Diameter: 1.6 - 6.0

  • Electrode type: 6010 6011/6013 7018

MACHINE C/W:

  • LT 500 x 4M ELECTRODE HOLDER

  • LT 500 x 3M EARTH CABLE

  • Heavy Duty 4 Wheel Trolley

KEY BENEFITS:

  1. TIG Stick Mode - Possibility of welding with TIG stick mode.

  2. Digital display - Digital control of all the welding parameters, Easy to understand graphic panels.

  3. Eletrocles diameter - from 1.6 to 5.0mm.

  4. Extra function - Adjustable Hot Start/Arc Force, Anti-sticking automatic.

  5. Protections - Equipped with temperature, voltage and current sensors for high protection.

  6. Arc gouging capability.

  7. When you have a wrong gird voltage, the machine will stop working immediately and the key core will be protected from damage, especially the IGBT.

  8. Standard triple phase 3-400V 50/60Hz power supply.

  9. Excellent performance on 60% electrodes.

  10. Smart FAN - Reduce power consumption and the intake of dust and fumes.

  11. When the "V.R.D" mode on the output voltage is only 14.5V, it's absolutely safe for welders.

  12. Zero V/C Switch

  13. Heavy Duty Cycle 60% for industrial use.

  14. Digital control system - the welding parameter can be controlled easier and more precisely.

  15. Generator Friendly- Suitable for use with generators.

  16. 550V Tested In Production

  17. IGBT Module

  18. Support Full range of Electrode E;- 6013,7018,7016,7015,8018,9018,11018,cellulose 6011,6010,7010,8010. Pipeline 8045,9045. Stainless Steel,Duplex,Inconel,Aluminium.

✅ Note: Feat Craft machine comes with Calibration and Validation report according to ISO 60974

✅ Machine Warranty: 2 Years

✅ Machines come with parts obtainable guarantee:-  Machine spare parts available for 10 years

✅ Come with maintenance training

✅ Schedule maintenance inspection for next 2 years
